Actual signals and parameters
What this chapter contains
The chapter describes the actual signals and parameters related to high speed
program and gives the fieldbus equivalent values for each signal/parameter.
Terms and abbreviations
Note: More information about drive parameters please refer to the section Actual
signal and parameters in ACS355 User’s manual (3AUA0000066143 [English]).
Term Definition
Actual signal Sequence program related signals measured or calculated by the drive. Can
be monitored by the user. No user setting possible.
Def Parameter default value
Parameter A user-adjustable sequence program operation instruction of the drive. Note:
Parameter selections are shown on the basic control panel as integer values.
Eg parameter 1001 EXT1 COMMANDS selection COMM is shown as value
10 (which is equal to the fieldbus equivalent FbEq).
FbEq Fieldbus equivalent: The scaling between the value and the integer used in
serial communication.
