26 Actual signals and parameters
USER S2
SAVE
Save User 2 macro. Stores the current parameter settings
and the motor model.
-3
USER S3
LOAD
User 3 macro loaded into use. Before loading, check that
the saved parameter settings and the motor model are
suitable for the application.
-4
USER S3
SAVE
Save User 3 macro. Stores the current parameter settings
and the motor model.
-5
USER S4
LOAD
User 4 macro loaded into use. Before loading, check that
the saved parameter settings and the motor model are
suitable for the application.
-6
USER S4
SAVE
Save User 4 macro. Stores the current parameter settings
and the motor model.
-7
USER S5
LOAD
User 5 macro loaded into use. Before loading, check that
the saved parameter settings and the motor model are
suitable for the application.
-8
USER S5
SAVE
Save User 5 macro. Stores the current parameter settings
and the motor model.
-9
USER S6
LOAD
User 6 macro loaded into use. Before loading, check that
the saved parameter settings and the motor model are
suitable for the application.
-10
USER S6
SAVE
Save User 6 macro. Stores the current parameter settings
and the motor model.
-11
9907 MOTOR NOM
FREQ
Defines the nominal motor frequency, ie the frequency at
which the output voltage equals the motor nominal voltage:
Field weakening point = Nom. frequency · Supply voltage /
Motor nom. voltage
E: 50.0 Hz
U: 60.0 Hz
0.0…1400.0 Hz Frequency 1 = 0.1 Hz
9908 MOTOR NOM
SPEED
Defines the nominal motor speed. Must be equal to the
value on the motor rating plate.
Type
dependent
50…32000 rpm Speed 1 = 1 rpm
All parameters
No. Name/Value Description Def/FbEq
