Technical data 121
10
Technical data
What this chapter contains
This chapter contains technical data of the ACS800-67LC, eg, ratings, frame sizes,
technical requirements and provisions for fulfilling the requirements for CE and other
markings.
Ratings
The ratings for the converter with 50 Hz and 690 V AC power supply network are given
below.
 Grid-side converter ratings
For information on reactive power capability, see ACS800-67LC system description and
start-up guide [3AUA0000059432 (English)].
ACS800-204LC
Frame
size
Nominal ratings
I
cont.max
A (AC)
S
cont.max
kVA
Q
cont.max
kVAr
I
max
A (AC)
Three-phase supply voltage: 525…690 V
-0575-7+E205 R8i 480 574 470 718
-0865-7+E205 2×R8i 720 860 706 1077
-1125-7+E205 2×R8i 941 1124 922 1407
