Mechanical installation 47
2. Remove the lifting bars. Use the holes for fastening the cabinet from top. Use the
original bolts to block any unused holes.
Fastening the cabinet to the roof
If the converter is installed in a nacelle, the cabinet roof must be fixed to the nacelle
structure for roof support. Roof support kit is included in the delivery as standard.
The lifting lugs on the top of the cabinet are replaced with the roof support. Support for
both sides of the cabinet roof is required.
