ABB ACS800 - Assembling Busbars on Pedestal: Frame Size R7 (+H356;+H360)

Assembly drawings
156
Adding UDC+/R+, UDC- and R- busbars to the pedestal (frame size R7,
+H356+H360)
Step 2
UDC- busbars
Combi screw
Step 1
R- busbars
Step 3
UDC+/R+ busbars
6844855 A
Combi screw
Combi screw
Combi screw
Combi screw
Combi screw
Combi screw
Combi screw
Combi screw
Basic assembly
