Mechanical installation of non-pre-assembled units (ACS800-04M)
75
5
Fastening by
top
base-mounted
unit
See Fastening the drive module by top to the cabinet frame on
page 81.
6
Fastening
shrouds
if included Frame size R7
See Top entry busbar shroud in section Fastening the top entry
busbar and bottom exit shrouds (+B060) on page 55.
Frame size R8
See Fastening the shrouds in frame size R8 on page 90.
