Parameters 449
85.34 Upthrust head 3 See parameter 85.14 Upthrust head 1 (page 448). 0.00
85.35 Upthrust flowrate 3 See parameter 85.15 Upthrust flowrate 1 (page 448). 0.00
85.36 DNT zone 50%
Head 3
See parameter 85.16 DNT zone 50% Head 1 (page 448). 0.00
85.37 UPT zone 50%
Head 3
See parameter 85.17 UPT zone 50% Head 1 (page 448). 0.00
85.38 Workzone 1/3 Head
3
See parameter 85.18 Workzone 1/3 Head 1 (page 448). 0.00
85.39 Workzone 2/3 Head
3
See parameter 85.19 Workzone 2/3 Head 1 (page 448). 0.00
85.40 Head at 0 flowrate 4 See parameter 85.10 Head at 0 flowrate 1 (page 447). 0.00
85.41 Flowrate max 4 See parameter 85.11 Flowrate max 1 (page 447). 0.00
85.42 Downthrust head 4 See parameter 85.12 Downthrust head 1 (page 447). 0.00
85.43 Downthrust flowrate
4
See parameter 85.13 Downthrust flowrate 1 (page 448). 0.00
85.44 Upthrust head 4 See parameter 85.14 Upthrust head 1 (page 448). 0.00
85.45 Upthrust flowrate 4 See parameter 85.15 Upthrust flowrate 1 (page 448). 0.00
85.46 DNT zone 50%
Head 4
See parameter 85.16 DNT zone 50% Head 1 (page 448). 0.00
85.47 UPT zone 50%
Head 4
See parameter 85.17 UPT zone 50% Head 1 (page 448). 0.00
85.48 Workzone 1/3 Head
4
See parameter 85.18 Workzone 1/3 Head 1 (page 448). 0.00
85.49 Workzone 2/3 Head
4
See parameter 85.19 Workzone 2/3 Head 1 (page 448). 0.00
85.50 Head at 0 flowrate 5 See parameter 85.10 Head at 0 flowrate 1 (page 447). 0.00
85.51 Flowrate max 5 See parameter 85.11 Flowrate max 1 (page 447). 0.00
85.52 Downthrust head 5 See parameter 85.12 Downthrust head 1 (page 447). 0.00
85.53 Downthrust flowrate
5
See parameter 85.13 Downthrust flowrate 1 (page 448). 0.00
85.54 Upthrust head 5 See parameter 85.14 Upthrust head 1 (page 448). 0.00
85.55 Upthrust flowrate 5 See parameter 85.15 Upthrust flowrate 1 (page 448). 0.00
85.56 DNT zone 50%
Head 5
See parameter 85.16 DNT zone 50% Head 1 (page 448). 0.00
85.57 UPT zone 50%
Head 5
See parameter 85.17 UPT zone 50% Head 1 (page
448). 0.00
85.58 Workzone 1/3 Head
5
See parameter 85.18 Workzone 1/3 Head 1 (page 448). 0.00
85.59 Workzone 2/3 Head
5
See parameter 85.19 Workzone 2/3 Head 1 (page 448). 0.00
85.60 Curve fine tune
enable
Defines the source for the curve fine tune enable signal.
When the function is active, the user can adjust the actual
curvature for each of seven segments of the defined pump
curves with parameters 85.61...85.67.
Not selected
Not selected Curve fine tune enable function is not selected. 0
Selected Curve fine tune enable function is selected. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
No. Name/Value Description Def/FbEq16
