Parameters 471
93.13 Position data width (Visible when an absolute encoder is selected)
See parameter 92.13 Position data width.
0
93.14 Speed estimation
enable
(Visible when a TTL, TTL+ or HTL encoder is selected)
See parameter 92.14 Speed estimation enable.
Disable
93.14 Revolution data
width
(Visible when an absolute encoder is selected)
See parameter 92.14 Revolution data width.
0
93.15 Transient filter (Visible when a TTL, TTL+ or HTL encoder is selected)
See parameter 92.15 Transient filter.
4880 Hz
93.16 Encoder 2 supply
voltage
(Visible when parameter 93.01 Encoder 2 type = HTL 1 or
HTL 2)
See parameter 92.16 Encoder 1 supply voltage.
0V
93.17 Accepted pulse freq
of encoder 2
(Visible when parameter 93.01 Encoder 2 type = HTL 1 or
HTL 2)
See parameter 92.17 Accepted pulse freq of encoder 1.
0 kHz
93.21 Encoder cable fault
mode
(Visible when a TTL, TTL+ or HTL encoder is selected)
See parameter 92.21 Encoder cable fault mode.
A, B
93.23 Maximum pulse
waiting time
(Visible when parameter 93.01 Encoder 2 type = TTL or HTL)
See parameter 92.23 Maximum pulse waiting time.
4 ms
93.24 Pulse edge filtering (Visible when parameter 93.01 Encoder 2 type = HTL
)
See parameter 92.24 Pulse edge filtering.
No filtering
93.25 Pulse
overfrequency
function
(Visible when parameter 93.01 Encoder 2 type = HTL)
See parameter 92.25 Pulse overfrequency function.
Fault
93.30 Serial link mode (Visible when an absolute encoder is selected)
See parameter 92.30 Serial link mode.
Initial position
93.31 EnDat calc time (Visible when an absolute encoder is selected)
See parameter 92.31 EnDat max calculation time.
50 ms
93.32 SSI cycle time (Visible when an absolute encoder is selected)
See parameter 92.32 SSI cycle time.
100 us
93.33 SSI clock cycles (Visible when an absolute encoder is selected)
See parameter 92.33 SSI clock cycles.
2
93.34 SSI position msb (Visible when an absolute encoder is selected)
See parameter 92.34 SSI position msb.
1
93.35 SSI revolution msb (Visible when an absolute encoder is selected)
See parameter 92.35 SSI revolution msb.
1
93.36 SSI data format (Visible when an absolute encoder is selected)
See parameter 92.36 SSI data format.
Binary
93.37 SSI baud rate (Visible when an absolute encoder is selected)
See parameter 92.37 SSI baud rate.
100 kBit/s
93.40 SSI zero phase (Visible when an absolute encoder is selected)
See parameter 92.40 SSI zero phase.
315-45 deg
93.45 Hiperface parity (Visible when an absolute encoder is selected)
See parameter 92.45 Hiperface parity.
Odd
93.46 Hiperface baud rate (Visible when an absolute encoder is selected)
See parameter 92.46 Hiperface baud rate.
4800 bits/s
93.47 Hiperface node
address
(Visible when an absolute encoder is selected)
See parameter 92.47 Hiperface node address.
64
No. Name/Value Description Def/FbEq16
