￭ Separate control cable ducts
Lead 24 V DCand 230 V AC (120 V AC) control cables in separate ducts unless the 24 V DC
cable is insulated for 230 V AC (120 V AC) or insulated with an insulation sleeving for
230 V AC (120 V AC).
24 V DC
230 V AC
(120 V AC)
230 V AC
(120 V AC)
24 V DC
