ACS880 liquid-cooled multidrive

cabinets and modules

Electrical planning

Table of contents

EFFECTIVE: 2019-06-30

Main Page

Table of Contents5
Introduction to the Manual9
Contents of this Chapter9
Applicability9
Safety Instructions9
Target Audience9
Terms and Abbreviations10
Related Documents11
Cabinet-Installed Multidrive Manuals11
Multidrive Module Manuals11
Electrical Planning Guidelines13
Contents of this Chapter13
Limitation of Liability13
Selecting the Supply Disconnecting Device13
Cabinet-Installed Multidrives13
Multidrive Modules13
European Union13
North America14
Other Regions14
Selecting the Main Contactor (Breaker)14
Cabinet-Installed Multidrives14
Multidrive Modules14
Selecting the Supply Transformer15
Cabinet-Installed Multidrives15
Basic Guidelines15
Additional Notes16
Multidrive Modules17
IGBT Supply Modules ACS880-204LC17
Diode Supply Modules ACS880-304LC+A01917
Examining the Compatibility of the Motor and Drive18
Protecting the Motor Insulation and Bearings18
Requirements Table18
Availability of Du/Dt Filter and Common Mode Filter by Drive or Inverter Type21
Additional Requirements for Explosion-Safe (EX) Motors21
And am21
Additional Requirements for Braking Applications21
Additional Requirements for Drives with an IGBT Supply Unit or Regenerative Rectifier Unit21
Additional Requirements for ABB High-Output and IP23 Motors21
Additional Requirements for Non-ABB High-Output and IP23 Motors22
Additional Note for Sine Filters22
Selecting the Power Cables23
General Guidelines23
Typical Power Cable Sizes23
Power Cable Types24
Recommended Power Cable Types24
Alternate Power Cable Types24
Not Allowed Power Cable Types25
Power Cable Shield25
Selecting the Control Cables27
Shielding27
Signals in Separate Cables27
Signals that Can be Run in the same Cable27
Relay Cable Type27
Control Panel to Drive Connection27
Routing the Cables28
General Guidelines, IEC28
Continuous Motor Cable Shield or Enclosure for Equipment on the Motor Cable28
Separate Control Cable Ducts29
Implementing Thermal Overload and Short Circuit Protections30
Protecting the Input Power Cable against Thermal Overload30
Diode Supply Unit30
IGBT Supply Unit30
Protecting the Input Power Cable in Short-Circuits30
Protecting the Drive against Thermal Overload30
Cabinet-Installed Multidrives30
Multidrive Modules30
Protecting against Short-Circuit Inside the Drive31
Cabinet-Installed Multidrives31
Multidrive Modules31
Protecting the Motor and Motor Cable in Short-Circuits31
Protecting the Motor Cables against Thermal Overload31
Protecting the Motor against Thermal Overload31
Implementing a Motor Temperature Sensor Connection32
Connecting Motor Temperature Sensor to the Drive Via an Option Module32
Connection of Motor Temperature Sensor to the Drive Via a Relay33
Implementing a Ground Fault Protecting Function34
Cabinet-Installed Multidrives34
Residual Current Device Compatibility34
Multidrives Modules34
Implementing the Emergency Stop Function34
Multidrive Modules35
Implementing the Safe Torque off Function35
Implementing the Prevention of Unexpected Start-Up Function35
Cabinet-Installed Multidrives35
Implementing the Safely-Limited Speed Function35
Multidrive Modules36
Implementing the Functions Provided by the FSO-XX Safety Functions Module36
Cabinet-Installed Multidrives36
Supplying Power for the Auxiliary Circuits36
Using Power Factor Compensation Capacitors with the Drive37
Using a Safety Switch between the Drive and the Motor37
Implementing the Power-Loss Ride-Through Function37
Implementing the Control of a Contactor between Drive and Motor37
Implementing a Bypass Connection38
Protecting the Contacts of Relay Outputs38
Standards and Markings41
Contents of this Chapter41
Applicable Standards41
Markings42
EMC Compliance (IEC/EN 61800-3:2004 + A2012)43
Definitions43
Category C343
Category C443
EU Declaration of Conformity (Machinery Directive)45
Multidrive Modules45
Cabinet-Installed Multidrives46
Approvals46
Disclaimers47
Generic Disclaimer47
Cybersecurity Disclaimer47
Further Information49
