DescriptionTerm
Safety integrity level (1...3) (IEC 61508)SIL
Safe stop 1 (IEC/EN 61800-5-2)SS1
Safe stop emergencySSE
Safe torque off (IEC/EN 61800-5-2)STO
There are three categories of stop functions:
• stop category 0: an uncontrolled stop where power to the machine actuators is re-
moved immediately (STO)
• stop category 1: a controlled stop where the machine actuators have power for
stopping, after which the power is removed (SS1)
• stop category 2: a controlled stop where the machine actuators continue to have
power SS2).
Stop category
Proof test interval. Defines the probabilistic failure rate (PFH or PFD
avg
) for the safety
function or subsystem. Performing a proof test at a maximum interval of T
1
is required
to keep the SIL capability valid. The same interval must be followed to keep the PL
capability (EN ISO 13849) valid. Note that any T
1
values given cannot be regarded
as a guarantee or warranty.
T
1
Mission time: the period of time covering the intended use of the safety function/device.
After the mission time elapses, the safety device must be replaced. Note that any T
M
values given cannot be regarded as a guarantee or warranty. (EN ISO 13849-1)
T
M
Potentially explosive atmosphere. Hazardous areas are divided into zones, based on
the frequency and duration of the occurrence of an explosive atmosphere. (EN/IEC
60079)
Zone
Later in this manual, the term “drive” is used to refer to drives, drive modules and inverter
modules.
Related manuals
CodeManual
Drive hardware
3AUA0000078093ACS880-01 drives (0.55 to 250 kW) hardware manual
3AUA0000128301ACS880-04 drive modules (200 to 710 kW, 300 to 700 hp) hardware manual
3AUA0000138495ACS880-04 single drive module packages hardware manual
3AXD50000025169ACS880-04XT drive modules (500 to 1200 kW) hardware manual
3AXD50000034664ACS880-04F drive modules hardware manual
3AXD50000274444ACS880-04FXT drive module packages hardware manual
3AXD50000028613ACS880-M04 Machinery drive hardware manual
3AXD50000045932ACS880-11 hardware manual
3AXD50000045933ACS880-31 hardware manual
3AXD50000022021ACS880-14 and -34 single drive module packages hardware manual
3AUA0000102324ACS880 multidrive cabinets and modules electrical planning instructions
3AXD50000048634ACS880 liquid-cooled multidrive cabinets and modules electrical planning
Inverter units
3AUA0000104271ACS880-104 inverter modules hardware manual
3AXD50000045610ACS880-104LC inverter modules hardware manual
Drive firmware
3AUA0000085967ACS880 primary control program firmware manual
3AUA0000098062ACS880 primary control program quick start-up guide
Introduction 13
