CAM CHARACTERIZATION
CAM SELECTION
C - 4
2. Plot the exact control medium versus control signal character-
istic given or desired for the application. This is usually a linear
function (Fig. C-5).
NOTE: If angularity is introduced into the drive linkage, replot the
controlled medium versus piston travel curves. In all cases,
avoid overstroking the final control device.
Figure C-4. Regulated Device Characteristics
Figure C-5. Desired Control
100
40
10
20
30
90
50
60
70
80
0
%OFPISTON
OR VALVE
TRAVEL
%OFCONTROLLEDMEDIUM
T00795A
02030405010 60 70 80 90 100
100
40
10
20
30
90
50
60
70
80
0
%OF
SIGNAL
% OF CONTROLLED MEDIUM
T00794A
0 2030405010 60 70 80 90 100
