Wiring with the logic relay
110
1SVC 440 795 M0100
Example: Analog value comparator, comparison of
two analog values
To compare two analog values, you can use the following
circuit. In this case, the comparison determines whether I7 is
less than I8.
Parameter settings of the analog value comparator.
First operating state
Second operating state Third operating state
A6 EQ +
I1 I7 Æ
F1 +0
I2 0500 æ
F2 +0
OS +0
HY 0025
A7 EQ +
I1 I7 Æ
F1 +0
I2 0700 æ
F2 +0
OS +0
HY 0025
A8 EQ +
I1 I7 Æ
F1 +0
I2 0850 æ
F2 +0
OS +0
HY 0025
A1-------ÄM9
A1 LT +
I1 I7 Æ
F1 +0
I2 I8 æ
F2 +0
OS +0
HY 0025
To Next Page
