Installation
32
1SVC 440 795 M0100
Supplying AC units
Supplying AC basic units
CL-LSR...12AC1,CL-LMR...18AC1,
CL-LSR...12AC2,CL-LMR...18AC2
Figure 7: Supply voltage to AC basic unit
Supplying AC basic units
CL-LER.18AC2
Figure 8: Supply voltage to AC basic unit
NNL
N
F1
L
NNL
N
F1
L
E+
E-
R1
...
R12
