Technical data
257
1SVC 440 795 M0100
Power supply
CL-LSR...AC1, CL-LMR...AC1, CL-LSR...AC2,
CL-LMR...AC2
CL-LSR...AC1,
CL-LMR...AC1
CL-LSR...AC2,
CL-LMR...AC2
Rated value (sinusoidal) 24 V AC 100/110/115/120/230/240 V AC
Operating range +10/–15 %
20.4 to 26.4 V AC
+10/–15 %
85 to 264 V AC
Frequency, rated value,
tolerance
50/60 Hz,  5 % 50/60 Hz, 5 %
Input current consumption
CL-LSR...AC1 CL-LMR...AC1 CL-LSR...AC2 CL-LMR...AC2
at 115/120 V AC 60 Hz Normally 40 mA Normally 70 mA
at 230/240 V AC 50 Hz Normally 20 mA Normally 35 mA
at 24 V AC 50/60 Hz
Normally 200 mA Normally 300 mA
Voltage dips 20 ms, IEC/EN 61131-2 20 ms, IEC/EN 61131-2
Power loss CL-LSR...AC1 CL-LMR...AC1 CL-LSR...AC2 CL-LMR...AC2
at 115/120 V AC Normally 5 VA Normally 10 VA
at 230/240 V AC Normally 5 VA Normally 10 VA
at 24 V AC Normally 5 VA Normally 7 VA
