Wiring with the logic relay
116
1SVC 440 795 M0100
Example: Counting unit quantities, automatic counter
value reset
The input I6 contains the necessary counter information and
controls the count coil CC2 of counter 2. M8 will be switched
on for one program cycle if the setpoint is reached. The
counter C2 is automatically set to zero by the reset coil RC2.
Circuit diagram display Parameter settings of the
counter C1
Circuit diagram display Parameter settings of the
counter C2
I6-------CC1
C1-------ÄQ4
I7-Q4----RC1
C1 N +
S 00100
I6-------CC2
C2------uÄM8
hRC2
C2 N +
S 01000
