Technical data
261
1SVC 440 795 M0100
CL-LSR...DC1, CL-LMR...DC1
CL-LSR...DC1 CL-LMR...DC1
Digital inputs
Quantity 8 12
Inputs usable as analog inputs I7, I8 I7, I8, I11, I12
Status display LCD (if provided) LCD (if provided)
Potential isolation
To power supply No No
Between each other No No
To the outputs Yes Yes
Rated voltage
Nominal value 12 V DC 12 V DC
At state ”0” 4 V DC (I1 to I8) 4 V DC (I1 to I12)
At state ”1” 8 V DC (I1 to I8) 8 V DC (I1 to I12)
Input current for state “1” 3.3 mA at 12 V DC
(I1 to I6)
3.3 mA at 12 V DC
(I1 to I6, I9 to I12)
I7, I8 1.1 mA at 12 V DC 1.1 mA at 12 V DC
Delay time for 0 to 1
Debounce ON 20 ms 20 ms
Debounce OFF Normally 0.3 ms (I1 to I16)
Normally 0.35 ms (I7, I8)
Normally 0.3 ms (I1 to I6, I9, I10)
Normally 0.35 ms (I7, I8, I11, I12)
Delay time from 1 to 0
Debounce ON 20 ms 20 ms
Debounce OFF Normally 0.3 ms (I1 to I16)
Normally 0.15 ms (I7, I8)
Normally 0.4 ms (I1 to I6, I9 to I12)
Normally 0.2 ms (I7, I8, I11, I12)
Cable length (unscreened) 100 m 100 m
