ABB CL-LMR 18AC2 Series User Manual

Appendix
266
1SVC 440 795 M0100
UL/CSA
Breaking capacity
AC-15 250 V AC, 3 A (600 Ops/h) 300 000 operations
DC-13 L/R F 150 ms 24 V DC,
1 A (500 Ops/h)
200 000 operations
Filament bulb load
1000 W at 230/240 V AC/25000 operations
500 W at 115/120 V AC/25000 operations
Fluorescent tube with ballast
10 x 58 W at 230/240 V AC/25000 operations
Conventional fluorescent tube,
compensated
1 x 58 W at 230/240 V AC/25000 operations
Fluorescent tube, uncompensated
10 x 58 W at 230/240 V AC/25000 operations
Operating frequency, relays
Mechanical switching operations 10 million (1 x 10
7
)
Mechanical switching frequency
10 Hz
Resistive lamp load
2 Hz
Inductive load
0.5 Hz
CL-LSR CL-LMR,
CL-LER.18AC2,
CL-LER.18DC2
CL-LER.2O
Uninterrupted current at 240 V AC/24 V DC 10/8 A
AC Control Circuit Rating Codes
(Utilization category)
B300 Light Pilot Duty
Max. rated operational voltage 300 V AC
Max. uninterrupted thermal current y = 1 at B 300 5 A
Maximum make/break capacity y k 1 (Make/break)
with B300
3600/360 VA
DC Control Circuit Rating Codes
(Utilization category)
R300 Light Pilot Duty
Max. rated operational voltage 300 V DC
Max. thermal uninterrupted current with R300 1 A
Maximum apparent on/off power with R300 28/28 VA
