Appendix
268
1SVC 440 795 M0100
Inductive load (without external suppressor circuit)
General explanations:
T
0.95
= time in milliseconds until 95 % of the stationary
current is reached.
Utilisation category in groups for:
•Q1 to Q4
•Q5 to Q8
•S1 to S4
•S5 to S8
Max. switching frequency with
constant resistive load
R
L
100 kO: operations/hour
40000 (depends on program and load)
Parallel connection of outputs
with resistive load; inductive
load with external suppression
circuit (see page 53)
Combination within a group
Group 1: Q1 to Q4 • Group 1:
Q1 to Q4, S1 to S4
• Group 2:
Q5 to Q8, S5 to S8
Number of outputs
max. 4 max. 4
Total maximum current 2.0 A, Attention! Outputs must be actuated simultaneously and
for the same time duration.
Status display of the outputs LCD display (if provided)
CL-LST CL-LMT,
CL-LET.20DC2
T
0,95
Q 3 x T
0,65
= 3 x
L
R
