4
CP1484, CP1485, CP1486, CP3484, CP3485, CP3486
Data sheet V 1.00
CPU and X2X Link supply
Input voltage 24 VDC (-15 % / +20 %)
Input current Max. 2.2 A
Reverse polarity protection Yes
Fuse Integrated, cannot be exchanged
X2X Link supply output
Rated output power 7.0 W
Parallel operation Yes
1)
Redundant operation of
X2X Link supply
Yes
I/O supply input
Input voltage 24 VDC (-15 % / +20 %)
Fuse Recommended pre-fusing max. 10 A slow-blow
I/O supply output
Rated output voltage 24 VDC
Allowable contact load 10.0 A
General supply
Status indicators Overload, operating status, module status
Diagnostics
Module run error
Overload
Yes, with status LED and software status
Yes, with status LED and software status
Electrical isolation
X2X bus supply
I/O supply
Yes
No
General information
Status indicators CPU function, overtemperature, Ethernet, ETHERNET Powerlink, CompactFlash, battery
Diagnostics
CPU function
Overtemperature
Ethernet
ETHERNET Powerlink
CompactFlash
Battery
Fans
Yes, with status LED
Yes, with status LED
Yes, with status LED
Yes, with status LED
Yes, with status LED
Yes, with status LED and software status
Yes, with software status
Visual Components capable Yes
ACOPOS™ capable Yes
Cooling Fan-free Fan-free with derating (see
operational conditions)
Exchangeable fans for entire
temperature range
Fan is monitored
Product ID CP1484 CP3484 CP1485 CP3485 CP1486 CP3486
Table 2: X20 CPUs - technical data (cont.)
