ABB CP1484 - Page 5

CP1484, CP1485, CP1486, CP3484, CP3485, CP3486
5Data sheet V 1.00
Electrical isolation
PLC - IF1/IF4/IF5
PLC - IF2/IF3
IF1/IF4/IF5 - IF2/IF3
IF1 - IF4/IF5
IF4 - IF5
No
Yes
Yes
No
No
Power consumption - without
memory card, interface module
or USB
10.5 W 10.5 W 10.5 W 10.5 W 13.5 W 13.5 W
Certification CE, C-UL-US (in development), GOST-R (in development)
Operational conditions
Operating temperature
Horizontal installation
Vertical installation
0 °C to +55 °C
0 °C to +50 °C
0 °C to +55 °C
Fan-free: 0 °C to +45 °C
0 °C to +55 °C,
Fan-free is not allowed
Humidity 5 to 95%, non-condensing
Mounting orientation Horizontal or vertical
Installation at altitudes
above sea level
0 - 2000 m
>2000 m
No derating
Reduction of environmental temperature by 0.5 °C per 100 m
Protection type IP20
Storage and transport
conditions
Temperature -25 °C to +70 °C
Humidity 5 to 95%, non-condensing
Mechanical characteristics
Dimensions (W x H x D) [mm] 150 x 99 x 85 200 x 99 x 85 150 x 99 x 85 200 x 99 x 85 150 x 99 x 85 200 x 99 x 85
Comment Order program memory (CompactFlash) separately
Backup battery included in delivery
X20 locking plate (right) included in delivery
Standard X20 terminal block (12-pin) included in delivery
Interface module slot covers included in delivery
1) In parallel operation, only 75 % of the rated power can be assumed. Please ensure that all parallel operating power supplies are
switched on and off simultaneously.
Product ID CP1484 CP3484 CP1485 CP3485 CP1486 CP3486
Table 2: X20 CPUs - technical data (cont.)
