DCS 400
DCS 500B / DCS 600
DCS 400 / DCS 500
Easy Drive
DCA 500 / DCA 600
DCE 400 plus
The drive module for standard applications
● Integrated field supply (max. 20 A)
● Accurate speed and torque control
● Extremely small and compact design
● Very easy installation and commissioning
● Express delivery
● Power range: 10...500 kW (13...670 HP)
The drive module for demanding
applications
● Free programming of software
● 6- and 12-pulse configuration up to 10 MW/
13,000 HP and more
● Plain text display
● Power range: 10...5000 kW (13...6700 HP)
Highly integrated panel
● Extremly small and compact design
● Contains:
● DCS 400 module
● AC fuses
● Auxiliary transformer
● Motor fan starter with protection
● Main contactor
● Power range: 20...130 kW (26...174 HP)
The complete standard cabinet solution
● Pre-engineered
● Easy installation and commissioning
● Protection class: IP 21
● Plain text display
● Short delivery time
● Power range: 50...1350 kW (65...1800 HP)
For complex, completely engineered Drive
System in common cabinet design
● Flexible and modular hardware structure
● 6- and 12-pulse configuration up to 18 MW/
23,000 HP and more
● Pre-programmed applications:
Metals, Cranes, P&P application, Mining
● Power range: 10...18000 kW (13...23000 HP)
DC Drives Product Portfolio
Since we aim to always meet the latest state-of-the-art
standards with our products, we are sure you will
understand when we reserve the right to alter particulars
of design, figures, sizes, weights, etc. for our equipment
as specified in this brochure.
