L2234
Emax
99/158
Model
Scale
Page No.
Doc. No.
Apparatus
1SDH000460R0002
L2778
Select the value you want from the list
and confirm pressing the ↵ key (enter).
Press ESC twice
Before accessing the Main Menu, the following box will appear:
Accept the new configuration
Reject the new configuration (the previous configuration is retained)
Change the previously input values.
To select the required option use the ↓ (arrow down), ↑ (arrow up) keys, and press ↵ (enter) to confirm.
14.4.3.1 Modification of basic configuration
No parameter settings can be made if the PR123/P unit is in alarm conditions.
The configuration of the unit must be done in EDIT mode.
Following the instructions given in par. 14.4.3, view the following on the display:
Change system date
Change system time
Select system language
To change the system password, select the relevant menu item and press ↵ (enter); then you will be prompted to enter the OLD password, and
afterwards you can input the new one twice.
Press ESC twice to return to the Main Menu
Before accessing the Main Menu, the following box will appear:
Accept the new configuration
Reject the new configuration (the previous configuration is retained)
Change the previously input values.
1/3
Confirm
Abort
Modify
Confirm
Programming
1/3
Confirm
Abort
Modify
Confirm
Programming
1/4
January 12, 2004
Time
Language
Date
System
4/4
****
Language
New Password
Time
System
Password
Enter password
0***
1/4
t=0.14b/(i -1)
0.02
T=13.5b/(i-1)
t=k/i
2
Function
Note: To set the system language, check that:
- the relay is set to local (when PR120/D-M is installed);
- the CB is open;
- the auxiliary power supply is installed (Vaux 24VDC and/or busbar voltage through PR120/V and/or PR030/B).
When anyone of these conditions is not complied with, the relay does not allow the language to be changed.
