ABB E2S 16 User Manual

L2234
Emax
98/158
Model
Scale
Page No.
Doc. No.
Apparatus
1SDH000460R0002
L2778
You will be prompted to input a Password
complete the password entry procedure (par. 14.3.6)
press the ↵ key (enter)
Change the date using the keys ↓ (arrow down)
↑ (arrow up) and confirm by pressing the ↵ key (enter).
Press ESC twice to return to the Main Menu.
Procedure requiring the confirmation of any programming
For instance, to change the Curve of the Protection L, the correct sequence is as follows:
Press ESC to access the Main Menu.
From the Main Menu select the item PROTECTIONS
press the ↵ key (enter)
From the Protections Menu select the item PROTECTION L
press the ↵ key (enter)
Date
Enter password
January 12, 2004
Password
Enter password
0***
N
10:22:53
400 A
(I )
1
1/5
Protections settings
Measures
Settings
Protections
Menu
1/5
Protections settings
Measurements
Settings
Protections
Menu
1/15
Overload
S Protection
S2 Protection
L Protection
Protections
From the Protection L Menu select the item CURVE
press the ↵ key (enter)
You will be prompted to input a Password
complete the password entry procedure (par. 14.3.6)
press the ↵ key (enter)
1/4
Threshold I1
Time T1
Function
L Protection
t=k/i
2
Password
Enter password
0***
