14.6.4 Error messages displayed in pop-up windows
All the messages that appear on the display in a pop-up window are described below.
Error message Description Notes
L2 Sensor Alarm for L2 phase current sensor Phase L2 sensor disconnected or faulty
L3 Sensor Alarm for L3 phase current sensor Phase L3 sensor disconnected or faulty
Ne Sensor Alarm for Ne phase current sensor Phase Ne sensor disconnected or faulty
Gext Sensor Alarm for Gext current sensor Gext sensor disconnected or faulty
TC disconnected Trip Coil disconnected or faulty
Rating Plug Rating Plug Error absent or faulty
Power factor Power factor error The power factor module is lower than the specified threshold
Phase cycle Phase cycle inverted
Invalid date Clock information lost
CB status CB status error Probable error in Q26 and/or Q27
Installation Key plug error
CB not defined
State of circuit-breaker inconsistent (Open/Closed)
Probable error in Q26 and/or Q27
Local Bus Local Bus error See par. 14.7
Contact wear Contact wear prealarm Contact wear ≥ 80%
L prealarm Protection L prealarm
T prealarm Protection T prealarm
Frequency range Frequency out of range
Warning Iw Iw threshold exceeded
Timing L Timing protection L
Timing S Timing protection S
Timing S2 Timing protection S2
Timing G Timing protection G
Timing Gext Timing protection Gext
Timing D Timing protection D
Timing U Timing protection U
Timing UV Timing protection UV
Timing OV Timing protection OV
Timing RV Timing protection RV
Timing RP Timing protection RP
Timing UF Timing protection UF
Timing OF Timing protection OF
Error message Description
Password error
Session impossible A programming session cannot be started due to a contingency (e.g. a timer-controlled delay still elapsing)
Value outside range Value beyond the established limits
Failed 1001/2001 Incongruence between thresholds of protections L and S (SET1/SET2)
Failed 1002/2002 Incongruence between thresholds of protections I and S (SET1/SET2)
Failed 1006/2006 Incongruence between thresholds of protections I and D (SET1/SET2)
Failed 1005/2005 Incongruence between thresholds of protections L and D (SET1/SET2)
Failed 1009/2009 Zone selectivity enabled in both protection D and S or S2
Failed 1003/2003 Incongruence between thresholds of protections L and S2 (SET1/SET2)
Failed 1004/2004 Incongruence between thresholds of protections I and S2 (SET1/SET2)
Failed 3001 Inconsistency as to language change
Failed 3002 Inconsistency on Rc toroid
Failed 3003 Inconsistency as to external Neutral configuration
Exception 6 Control temporarily unavailable
Unavailable Function temporarily unavailable
