14.7 Troubleshooting PR123/P unit
The following table lists a series of typical service conditions, to help you understand and solve hypothetical faults or malfunctions.
Note:
1. Before consulting the following table, check for any error messages appearing for some seconds on the display.
2. FN indicates the normal operation of the PR123/P.
3. In the case where the suggestions proposed do not lead to a solution of the problem, please contact the ABB SACE assistance service.
No. Situation Possible causes Suggestions
1 The trip test cannot be run 1. The busbar current is > 0 1. FN
2. The TC is not connected 2. Check the messages on the display
2 Trip times lower than expected 1. Threshold too low 1. Correct threshold
2. Curve too low 2. Correct curve
3. Thermal memory enabled 3. Exclude if not necessary
4. Incorrect Neutral Selection 4. Correct Neutral Selection
5. The SdZ is inserted 5. Exclude if not necessary
3 Trip times higher than expected 1. Threshold too high 1. Correct threshold
2. Curve too high 2. Correct curve
3. Curve I
2
t inserted 3. Exclude if not necessary
4. Incorrect Neutral Selection 4. Correct Neutral Selection
4 Rapid trip, with I3=Off Iinst tripped FN with short-circuit with high I
5 High earth I, but no trip happens 1. Incorrect selection of the sensor 1. Set int. or ext. sensor
2. Function G prevented with I>4In 2. FN
6 Display off 1. Vaux missing and the current and/or 1. FN, see 14.2.2.1
voltage are below the minimum value.
2. Temperature out of range 2. FN, see 14.2.9.8
7 The display is not back-lit Current and/or voltages below the FN
limit for lighting the display
8 Reading of I incorrect Current below the minimum threshold FN
that can be displayed
9 Reading of V, W and power 1) Connection error between VT 1) Check connections between VT and
factor incorrect and PR120/V PR120
2) Voltage parameter setting error 2) Set correct parameters
10 " Local Bus" message No communication between PR123/P 1. If not present, disable PR021/K,
on display and PR021/K see 14.5.4.4.5
2. Check bus connection
3. Check PR021/K
11 Message "" Function disabled or data out of FN
instead of expected data range
12 The expected trip does not occur Trip function disabled FN enable trip if necessary
13 No activation of the Unbalance Values of I out of range FN, see 14.2.9.5
U protection
14 No display of the opening data Vaux missing,the buffer capacitor FN, see 14.5.6.1
is discharged
15 The password is not requested The password has been disabled FN, re-enter the password with a value
other than 0000
16 Impossible to change any parameter PR123/P in alarm situation FN
17 " Temp. sensor" or Possible failure inside relay Contact ABB Sace
" Start-up" message
18 Invalid date 1. First installation FN see 13.4.3.1
2. Information lost due to power
failure
19 Untimely trip see 13.6.3
20 LED lighting see 13.6.1
21 The language cannot be changed 1. Relay remotely set 1. Set locally
2. CB not open 2. Open CB
3. Vaux or PR120/V or PR030/B 3. Power the relay
not installed
Error message Description
Invalid date Date has not been set
Parameters revised Programming session concluded correctly
Cancelled Programming session cancelled
Failed Programming session rejected
