5 Operation
LED indication
Operation status LED
LED
Indication
Description
LED on Adam
Green
Eva close, safety circuit closed
Green-Red (flash)
Eva close, safety circuit broken by a previous unit
Green-Red (flash fast)
Eva within ~2 mm of max sensing distance
Red
Eva distant, safety circuit broken
Information output signal attributes
When Eva is in contact with Adam, the information output of the unit (pin-5) is set either high (+24 VDC) or low (0
VDC) depending on four different input signals (pin-2):
 Dynamic signal - Dynamic signal input exist, i.e. the safety circuit is OK up until this unit
 No dynamic signal - Dynamic signal input does not exist, i.e. the safety circuit is interrupted before this
unit.
 +24 VDC - A constant +24 VDC signal is applied = high (H)
 0 VDC - The pin is connected to 0 VDC = low (L)
The information output signal depends on the input signal according to the table below. Note that if the safety is
interrupted, i.e. if Eva is away from Adam, the information output signal is always low (L).
Input signal (pin-2)
Dynamic signal
No dynamic signal
+24 VDC
0 VDC
Info output signal (pin-5)
High
High
Low
High
The delay for switching the information signal output from high to low (H  L) and low to high (L  H) is given in
the table below.
Info output signal switch
H  L
L  H
Delay
~ 135 ms
~ 2 ms
Warning! The information output signal is not a failsafe signal and should never be used for the safety purpose(s).
Please note!
This model of Eden is obsolete and has been replaced by Eden DYN
