ABB Eden - Technical data; Power supply; General

2TLJ172066M0201, rev. F 14 www.abb.com/jokabsafety
2015-02-09
7 Technical data
Manufacturer
Address
ABB JOKAB SAFETY
Varlabergsvägen 11
SE-434 39 Kungsbacka
Sweden
Power supply
Operating voltage
24 VDC +15 %, -25 %
Total current consumption
45 mA (55 mA with max information output)
Information output: Max 10 mA
Time delay t (in/out) Eden
t < 60 µs
General
Protection class
Eden: IP67
Eden E: IP69K
Ambient temperature
Eden
Eden E
Storage: -25…+70°C
Operation: -25…+70°C
Storage: -40…+70°C
Operation: -25…+70°C
Humidity range
35 to 85 % (with no icing or condensation)
Housing material
Eden: Based on polyamide, Macromelt OM646 (V0)
Protective housing (Eden E): Polyurethane (PU)
Connector
M12 5-pole male (Adam M12, Adam E 0.5 m M12)
5-pole cable 3 m (Adam 3 m)
5-pole cable 10 m (Adam 10 m, Adam E 10 m)
5-pole cable 20 m (Adam 20 m, Adam E 20 m)
Cables (5-pole + screen):
Material: PVC, UL2464
Cable size: ø5.7 mm
Conductor size: 0.34 mm
2
Size
See drawings below
Mechanical life
10
7
cycles
Weight
Eva: 26 g
Eva E: 36 g
Adam M12: 30 g
Colour
Yellow or grey depending on model, black text
Maximum detection distance
(Hysteresis approx 1 mm)
Eden: 15 +/- 2 mm
Eden E: 12 +/- 2 mm
Assured release distance (S
ar
)
Eden: 45 mm
Eden E: 36 mm
Assured operating distance (S
ao
)
Eden: 7.5 mm
Eden E: 6 mm
Chemical resistance
Macromelt
(Eden and Eden C)
Cutting oils, vegetable and animal oils, hydrogen peroxide, diluted acids and bases: Good.
Alcohol and strong acids: Not recommended.
Polyurethane (PU)
(Eden E and Eden EC)
Cutting oils, vegetable and animal oils, hydrogen peroxide, diluted acids and bases,
alcohol: Good.
Strong oxidation acids: Not recommended.
Please note!
This model of Eden is obsolete and has been replaced by Eden DYN
