ABB Emax 2 Manual

Tabella di abbinabilità
Compatibility table
Kompatibilitätstabelle
Tableau de compatibilité
Tabla de compatibilidad
(1)
= Icw 500 ms
(2)
= 3P Only
AEG ME05
nameplate
Iu [A] Emax2 Iu [A]
Iu [A]
(Rating Plug)
Derating
[A]
Icm 690V
[kA]
Icu 690V
[kA]
Icw (690V, 1s)
[kA]
ME 1605 1900 E1.2N 1600 - 1450 105 50
50
(1)
ME 2505 2900 E4.2H 3200 - - 180 80 80
ME 3205 3900
E4.2H
(2 )
3200 - 3200 180 80 80

ABB Emax 2 Specifications

General

Breaking Capacity	Up to 150 kA
Number of Poles	3 or 4
Standards	IEC 60947-2
Rated insulation voltage	1000V AC
Mounting	Fixed, Withdrawable
