Tabella di abbinabilità
Compatibility table
Kompatibilitätstabelle
Tableau de compatibilité
Tabla de compatibilidad
AEG
SIZE
SIZE
ABB
ME1257N
ME1257S1
ME1257H
ME2007N
ME2007S1
ME2007H
ME2507N
ME2507S1
ME2507H
ME3207N
ME3207S1
ME3207H
1250A
1250A
1250A
1250A
1250A
1250A
2000A
2000A
2000A
2000A
2000A
2000A
2500A
2500A
2500A
2500A
2500A
2500A
3200A
3200A
3200A
3200A
3200A
3200A
E1.2 B
E1.2 N
NOT AVAILABLE
E2.2 B
E2.2 N
E2.2 H
E2.2 H (*)
E2.2 N
E2.2 N
E4.2 V
E4.2 V
E4.2 V
(*) = derating Icu 500V 85kA
derating Icm 500V 187kA
