￭ Installing the adapter vertically on a DIN rail
1. Attach the support bracket in the correct position on the wall.
2. Attach the latch to the back side of the adapter.
3. Click the adapter to the DIN rail.
4. Attach the adapter to the support bracket with two screws.
1
3
2
4
