ABB FETA-01 - Page 2

2
Signal connections for absolute encoder configurations
Signal connections for resolver configurations
Signal connections for TTL+ configurations
Note: The routing of zero pulses Z+/Z- for TTL+ are not supported via this adapter.
Terminal
X32 pin
123456789
Signal SIN+ SIN- COS+ COS- Z+, DATA+ Z-, DATA- SIN_CM+,
CLK+
SIN_CM-,
CLK-
ABS_COM
Terminal
X42 pin
123456
Signal PTC/KTY PTC/KTY_0V COS_CM+ COS_CM- ABS_VCC ABS_COM
Terminal
X32 pin
123456789
Signal SIN+ SIN- COS+ COS- Excitation+ Excitation-
Terminal
X42 pin
123456
Signal PTC/KTY PTC/KTY_0V COM
Terminal
X32 pin
123456789
Signal A- A+ B- B+ W+ W- V+ V- COM
Terminal
X42 pin
123456
Signal PTC U+ U- VCC_ENC COM
3AXD50000206063 Rev B (EN) 2019-01-24
