PRODUCT FAMILY: FSK II + - OPERATING AND MAINTENANCE MANUAL6 PRODUCT FAMILY: FSK II + - OPERATING AND MAINTENANCE MANUAL 6
1VSR630206EN – en – EDO-D0002852– Instruction manual – 2021.10 Design and specification are subject to change without notice
—
3. Product Description
 
 
Caption
1 Valve & protection for gas filling
2 Optional cable exit
3 Position sensors ON/OFF
4 Manual tripping catch
5 Heating resistance
6 Cable exit
7 Place for contact wear check
8 Operations counter
9 Mechanical position indicator
10 Magnetic actuator
Caption
1 Control panel
2 Capacitor bank
3 MABS board
4 “READY” indication
5 “ON” pushbutton
6 “OFF” pushbutton
7 Option : Capacitor fast
discharge
8 MABS support plate
9 Terminals

