3. Product Description
3.1. Apparatus



by their fast breaking times.


actuated mechanism instead of the conventional
mechanical spring charged mechanism. The main
insulators and the orientation of the HV terminals
can be configured according to the customer
requirements.
 
 
– EN CW004A
Connection’s range
available 1250
 
 
 
Connection’s range

Caption
1 Upper terminal
2 Insulator (polymer)
3 Lower terminal
4 Mounting plate
5 Cover panel
6 Drive unit
7 Identification plate
8 Access for manual tripping device (anti-clockwise direction of rotation)
