Installation and commissioning guide
1ZSC000563-ACF EN, REV. A, 2020-06-25
7
2 Product description
2.1 Design
Overview
The GOE(2) is a capacitance graded oil impregnated paper bushing made for immersed oil/air service.
For a detailed description, please refer to the Technical guide, 1ZSE 2750-105.
General schematics
G000378
9 Oil plug
26 Oil-level gauge
51 Oil sampling valve ¼”
65 Mounting flange
68 Top housing
69 Porcelain insulator, air side
70 Test tap
71 Extension for current transformer
72 Porcelain insulator, oil side
74 Lifting eye Ø 25 mm
78 End shield
79 Top end nut
