Installation and commissioning guide
1ZSC000563-ACF EN, REV. A, 2020-06-25
17
4 Installation
4.1 Tools
Tool Part number Note
Lifting tool 9760 668-C -
Soft bedding - E.g. rubber mat or wood board
Soft lifting slings - -
Pull-through cord 9760 669-A With M8 terminal.
For assembly and disassembly of the
draw rod and draw lead.
Torque wrench key for hexagon head
screws, head width 16 mm (M10) and 13
mm (M8).
- -
Wrench for hexagon head screws 45 mm
or adjustable wrench for 45 mm bolts
or larger.
- For the test tap cover.
Shackles - To fit Ø 25 mm holes, for connection of
the soft lifting slings to the bushing
flange.
Hydraulic jack 9769 897-A For removal, and installation of the
bottom contact. Draw-rod system.
Box spanner 9760 669-B For removal, and installation of the
bottom contact. Draw-rod system.
Tackle - For installation of the bushing at a
specific angle.
4.2 Consumables
Item Brand ABB part
number
Note
Oil based Vaseline Fuchs - For treatment of contact surfases. Does
not react with transformer oil.
Mobilgrease 28 MOBIL - Lubricates and protects metals against
corrosion. Protects rubber. Does not
react with transformer oil.
Molykote Multilub Dow Corning - For lubrication of draw-rod threads and
bolts on the outer terminal.
Thread-locking fluid
grade 42
- - High strength thread-locking fluid,
permanent locking.
Thread-locking activator
grade 47
- - Activator for thread-locking fluid
grade 42.
