Operation Manual / 4 Product description / A100-M axial
4 Monitoring during operation / 4.2 Turbocharger speed
© Copyright 2017 ABB. All rights reserved. HZTL4033_DE Revision B December 2017
4.2.4 Replacing the speed sensor
NOTICE
Sealing of the speed sensor
The speed sensor is designed with a sealing lip and does not require any ad-
ditional gasket for assembly.
u Connect cable connector (86515) with the speed sensor (86505).
u Switch on lubricating oil supply to the turbocharger.
4.2.5 Malfunction of the speed measurement system
The possible reasons for malfunction of the speed measurement system are described in
chapter Troubleshooting (Reasons for malfunction of the speed sensor).
Page 25 / 99
