Operation Manual / 4 Product description / A100-M axial
8 Disassembly and assembly / 8.6 Removing the cartridge group
© Copyright 2017 ABB. All rights reserved. HZTL4033_DE Revision B December 2017
8.6 Removing the cartridge group
CAUTION
Safety-relevant screws
The six screws (01) are relevant for containment safety and must not be
loosened.
Fig.33: Safety-relevant screws
Page 59 / 99
