Section 6 Data sets and control blocks
6.1 Data sets
SEMOD129786-5 v8
IEC 61850 has defined data sets and report control blocks to transmit signals for
monitoring purposes. Data sets are also used for GOOSE messages in horizontal
communication among IEDs. The project defines the data objects or single data
attributes that should be collected in a data set. Figure
8 shows a data set where all
position information of the apparatuses of a bay are put into one data set.
PCM600 will generate default data sets, based on the current ACT configuration.
The default data sets can be modified or removed in the engineering tools. No
RCBs are created automatically by PCM600. However, the configured IEDs are
delivered with RCBs for all default data sets or when templates (such as REC670
A30) are used.
1MRK 511 393-UEN A Section 6
Data sets and control blocks
670 series 2.2 IEC 37
Communication protocol manual
