NoteAction
Shown in the figure Location of
gearbox on page 156.
Refill the gearbox with clean lubricating oil.
The correct oil level is detailed in section Inspect-
ing the oil level in axis-5 gearbox on page 121.
4
Where to find type of oil and total
amount is detailed in Type and
amount of oil in gearboxes on
page 144.
Tightening torque: 24 Nm.Refit the oil plug, filling.5
158 Product manual - IRB 6660
3HAC028197-001 Revision: S
