39
M1M 20 POWER METER USER MANUAL
LOG
All alarms are by defaul in UNLOG mode, meaning that alarms are not stored in any flash memory.
However, it is still possible to read out the alarms in: READ NOTF ALM
CONF ALM LOG
After device restart, all alarms will be erased and it will not be possible to retrieve them.
PORT
Each alarm event can be connected with certain DO, and different alarms can be connected to the same
DO.
CONF ALM PORT
The optional DOs include DO1, DO2 and OFF.
Only the DOs configured as alarm output can appear in the list. For details, see “7.3.Input / output
(I/O)”.
