ABB M2004 Reference Manual

2 Spare part / part list
2.2. Spare part / part list
293HAC023297-001 Revision: A
35 1 3HAC 10477-2 Control cable spare CR L = 7 m
36 1 3HAC 11331-1 Control cable spare Std/F L = 15 m
37 1 3HAC 11331-2 Control cable spare CR L = 15 m
38 1 3HAC 13089-1 Control cable spare Std/F L = 30 m
39 1 3HAC 13090-1 Control cable spare Std/F L = 22 m
50 1 3HAC 10467-1 Gearbox axes 1-2, spare Std/F Item 67 incl.
51 2 3HAC 10469-1
3HAC 021965-001
Motor with pinion spare Std/F
52 24 3HAB 3409-25 Hex socket head cap screw M6x20 12.9
Gleitmo 610
53 18 9ADA 312-6 Plain washer 6.4x12x1.6
54 2 2152 2012-426 O-ring 74.5x3
55 1 3HAC 6788-1 Bearing hub
56 1 3HAC 10478-1 Console spare Std/F
57 1 3HAC 10472-1 Cover console spare Std/F Item 58 incl.
58 1 3HAC 7868-1 Gasket console-cover
59 1 3HAC 5894-1 Cable bracket T=1.5
60 1 3HAC 6965-1 Sealing ring 150x189x8.5
61 3 3HAC 3785-6 Parallel pin D = 6 m6 L = 16
62 2 3HAB 3732-19 Sealing ring (V-ring) 85x11
63 11 9ADA 618-55 Torx pan head screw M6x12
64 2 2166 2018-2 Clamp D = 11
65 1 3HAC 10481-1 Connector bracket
66 25 2166 2055-1 Cable straps, outdoors 2.5x101
67 3000 ml 1171 2016-604 Lubricating oil
68 1 3HAC 10467-3 Gearbox axes 1-2, spare CR
69 2 3HAC 10469-3 /
3HAC 021966-001
Motor with pinion, spare CR
70 1 3HAC 10478-3 Console, spare CR
71 1 3HAC 10472-3 Cover console, spare CR
72 1 3HAC 10645-1 Clamp D = 4.7
100 1 3HAC 10468-1 Lower arm (axis 3), spare Item 67, 107
and 108 incl.
101 1 3HAC 10471-1 Cover, without lamp unit Item 103 incl.
102 1 3HAC 10474-1 Cover, with lamp unit Item 103 incl.
103 1 3HAC 7869-1 Gasket lower-arm cover
104 1 3HAC 7866-1 /
3HAC 021756-001
Rot. ac motor incl. pinion
105 1 3HAC 6793-1 Timing belt
106 1 3HAC 6762-1 Belt shield
107 1 3HAB 3643-17 Groove ball bearing 80x100x10
108 2 3HAA 2166-13 VK-Cover D = 100 B = 10
109 1 3HAC 7880-1 Damper axis 2
110 1 3HAA 2356-14 Washer SRKB 6.4x18x1.6
Item Qty Art. no. Name Rem.
