CommentsImpact on process com-
munication
Function
Per Workplace with Measurement
Reports with 15 min report
Total of 900 objects data logged by
Measurement Reports
- 1%Reports Workpace with
data logging
The following list shows some examples when IEDs are connected to SYS 600C with
the following Gateway or NCC connections and with Local process database:
•
NCC connection with one DNP serial communication including 100 IEDs resulting
in 1 200 process updates per second sent to one NCC
•
NCC connection with two DNP LAN communications including 67 IEDs resulting
in 1 600 process updates per second sent to two NCCs
•
NCC connection with one IEC 104 LAN communication including 158 IEDs resulting
in 1 900 process updates per second sent to one NCC
•
NCC connection with two IEC 104 LAN communications including 116 IEDs res-
ulting in 2 800 process updates per second sent to two NCCs
The following list shows some examples when IEDs are connected to SYS 600C with
Local process database and displayed with Workplaces:
•
60 IEDs with IEC 61850 protocol and 1 Workplace with 1 050 display objects
•
63 IEDs with IEC 61850 protocol and 2 Workplaces both including 450 display
objects
•
77 IEDs with IEC 61850 protocol and 1 Workplace including 150 display objects
39
SYS 600C 1.92
MicroSCADA Pro
1MRS756804
Product Guide
