TypeProtocol
Master and slaveIEC 60870-5-104
ClientIEC 61850-8
MasterANSI X3.28 - AB (ABB)
Master and slaveRP 570
Master and slaveDNP 3.0 (Subset 3)
Master and slaveModbus
ClientOPC DA, A&E
ServerOPC DA, A&E
SYS 600C workplaces3.2.
Workplaces3.2.1.
SYS 600C can be equipped with 1 to 5 workplaces to be used at the same time. The
workplace provides means for the operator to configure the system and supervise and
interact with the process. Each SYS 600C computer can have a local workplace, but the
workplaces can also be distributed to other computers and locations.
The workstations can be distributed over a network using TCP/IP. It can be a LAN,
internet, or mobile wireless communication.
Each workplace can be used for engineering, supervision, and operation of the process.
The possibilities are defined by the access rights given to the user in question. Also the
layout and functions of the workplaces can be fully customized for each user.
The distributed workplace concept is based on available remote access techniques, typ-
ically Microsoft Terminal Server or Citrix Access Essentials. Any PC or other web-
enabled device can be used as a workstation without installing any additional software.
Process Display3.2.2.
One of the display types of the workplace is the process display. The process display is
used to represent the process and primary equipment, typically as a single-line diagram
with graphical symbols for primary devices, such as breakers, disconnectors, and trans-
formers. The process display is normally built with symbol libraries, but also customized
symbols and displays can be built.
The process display supports zooming, panning, and decluttering for efficient and clear
visualization of the information.
9
SYS 600C 1.92
MicroSCADA Pro
1MRS756804
Product Guide
