ABB NE810 - Environmental and Reliability Specifications; Type Tests and Environmental Conditions

Section 3 Location of interface ports and LED‘s
3BSE080633 23
Type Tests and Environmental Conditions
Environmental
phenomena
Basic standard Description Test levels
ESD EN 61000-4-2 Enclosure
Contact: ±6 kV
Air: ±8 kV
Fast transients EN 61000-4-4 Power port ±2 kV
Signal ports ±2 kV
Earth port ±1 kV
Surge EN 61000-4-5
Power port
L-E: ±0.5 kV, 12
Ohm, 9 µF
L-L: ±0.5 kV, 2
Ohm, 18 µF
L-E: ±2 kV, 42
Ohm, 0.5 µF
L-L: ±2 kV, 42
Ohm, 0.5 µF
L-E: ±2 kV, 12
Ohm, 9 µF
L-L: ±1 kV, 12
Ohm, 9 µF
Signal ports
L-E: ±1 kV, 2
Ohm
L-E: ±2 kV, 42Ohm, 0.5 µF
Power
frequency
magnetic eld
EN 61000-4-8 Enclosure 300 A/m; 0, 16.7, 50 Hz
