8 Quick Installation Guide – NextMove e100
Serial port
Ethernet interface
CAN interface
Environmental
Unit All models
Signal RS232 or RS485/422 non-isolated
Bit rates baud 9600, 19200, 38400,
57600 (default), 115200
Description Unit Value
Signal 2 twisted pairs, magnetically isolated
Protocols Ethernet POWERLINK & TCP/IP
Bit rates Mbit/s 100
Description Unit Value
Signal 2-wire, isolated
Channels 1
Protocol CANopen
Bit rates Kbit/s
10, 20, 50, 100, 125, 250, 500, 1000
Description Unit
Operating temperature range Min Max
°C
°F
0
+32
+45
+113
Maximum humidity % 80% for temperatures up to 31 °C (87 °F)
decreasingly linearly to 50% relative
humidity at 45 °C (113 °F),
non-condensing
Maximum installation altitude
(above m.s.l.)
m
ft
2000
6560
Shock 10 G according to
IEC 60068-2-6/27 or equivalent
Vibration 1 G, 10-150 Hz according to
IEC 60068-2-6/27 or equivalent
LT0305A01.book Page 8 Wednesday, June 21, 2017 2:10 PM
