Chapter 6 – Communication
6-2 NMBA-01 Installation and Start-up Guide
Table 6-1 Parameter Mapping
The register addresses which are not allocated to any drive parameter
or data set are invalid. No reads or writes are allowed for these
addresses. If there is an attempt to read or write outside the parameter
addresses, the Modbus interface will return an exception code to the
controller.
Refer to the drive manuals for its data sets, group and parameter
numbers supported.
4GGPP GG PP
Data sets
40001 – 40096 00 Data sets 01 Data word 1.1
02 Data word 1.2
03 Data word 1.3
04 Data word 2.1
05 Data word 2.2
06 Data word 2.3
07 Data word 3.1
...
94 Data word 32.1
95 Data word 32.2
96 Data word 32.3
Parameters
40101 – 40199 01 Group 01 01 Parameter 01
02 Parameter 02
...
99 Parameter 99
40201 – 40299 02 Group 02 01 Parameter 01
02 Parameter 02
...
99 Parameter 99
… ... ...
49901 – 49999 99 Group 99 01 Parameter 01
…
99 Parameter 99
