ABB OTM C Series - Mounting Positions; Labelling

17
1SCC303002M0204, rev. D
Installation and operating instructions, OTM_C
4.3 Mounting positions
The recommended mounting positions for motorized change-over switches are horizontal, wall mounted
or table mounted.
Do not install the motorized change-over switches in any other position than those
described above.
4.4 Labelling
Figure 4.17 Labelling of the motorized change-over switches
4. Installation
Figure 4.16 Mounting positions
