6.1 Mounting positions
The recommended mounting positions for motorized change-over switches are horizontal, wall
mounted or table mounted.
Figure 6.3 Labelling of the motorized change-over switches
Figure 6.2 Mounting positions
A06103
—
6.2 Labelling
II
M
M
Man.
Man.
M
M
Man.
Man.
I
A04128
1
2
Information
Do not install the motorized change-over switches in any other position than those
described above.
