Unmounting PDP32.0/PDR31.0
—
Electrical Installation
PROFIBUS Connection
General
General cabling instructions
• Arrange the bus cables as far away from the motor cables as possible
• Avoid parallel runs
• Use bushings at cable entries
•
X3 Description
Isolated ground
A
+5 V and GND can be used for bus termination only.
X4 Description
SHLD Alternate cable shield connection. Connected to connector housing
A
screw driver and move the PDP32
connection.
7 UNIVERSAL MOTOR CONTROLLER UMC100.3
